    Water Wcb / Cf8 / Cf8m/Thread End Globe Valve/SS globe valve/BS Standard Stainless Steel Globe Valve/SS valve

    Ask Lasest Price
    Brand Name : KIRI
    Model Number : GLOBE VALVE
    Certification : CE;ISO
    Price : flexible
    Payment Terms : L/C, T/T
    Supply Ability : flexible
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Water Wcb / Cf8 / Cf8m/Thread End Globe Valve/SS globe valve/BS Standard Stainless Steel Globe Valve/SS valve


    1) DESCRIPTION:


    Product name: Stainless steel female threaded globe valve
    Technology: Casting
    Connection type: Female threaded
    Size: From 1/4" to 4"
    Main material: CF8CF8M CF3, CF3M, WCB
    Working pressure: 1000 PSI WOG
    Temperature Range: -40° C~180° C~280° C
    Suitable medium: Water, oil, steam, nitric, acid, acetate acid and some corrosive liquids
    Thread standard: G. NPT, BSPT. BSP. DIN259/2999&
    Options:

    Body Material:ASTM A351-CF8M,CF8

    Key words:Globe Valve,Thread End 200WOG,G11F,1/2"-4",WCB/CF8/CF8M
    No.Parts nameMaterial
    ANSI/JIS/DINANSI/JIS/DIN
    1DiscSUS316SUS304
    2BodyA351-CF8M/SCS14A/1.4408A351-CF8/SCS13A/1.4308
    3StemSUS316
    4Cap gasketPTFE/RPTFE/PPL
    5CapA351-CF8M/SCS14A/1.4408A351-CF8/SCS13A/1.4308
    6The GasketSUS304
    7Stem packingPTFE/RPTFE/PPL
    8WasherSUS304
    9Packing nut glandA351-CF8M/SCS14A/1.4408A351-CF8/SCS13A/1.4308
    10Wheel HandleAluminum
    11Elastic gasketSUS304
    12Hexagon nutA194-8

    Unit:mm

    SizeLHE
    1/4"529570
    3/8"529570
    1/2"529570
    3/4"6610080
    1"7611080
    1-1/4"8613090
    1-1/2"95130100
    2"118150100

    Water Wcb / Cf8 / Cf8m/Thread End Globe Valve/SS globe valve/BS Standard Stainless Steel Globe Valve/SS valve

    Information for 316 stainless steel globe valve

    MaterialSUS201, SUS304,SUS316, SUS 304L , SUS 316L(CF8, CF8M),etc.
    Size1/4" -4" (DN6-DN100)
    pressure1000psi
    Temperature range-20-300 degree C
    connectionButt weld
    sealingPTFE,RPTFE,PPL ETC
    Production processInvestment casting, CNC lathe, Test, Cleaning, Packing, Storage
    CertificationCE, ISO, our factory has been inspected by SGS and TUV
    LockingWith or without
    Capacity to produce100,000.00pcs/week
    Main productsIncludes ball valve, butterfly valve, check valve, gate valve, strainer, etc.
    ApplicationSuitable for water, oil, air and some corrosive liquid etc
    Buyer’s drawings or designs are available
    PackageCartons without pallet
    Cartons with pallet
    Or as buyer’s requirements
    Delivery detailsAccording to the quantities and specifications of each order
    Normal delivery time is from 30 to 45 days after receiving the deposit
