Three-PC Stainless Steel Flanged Ball Valve 1000WOG, 304 / 316
Description:
Ball valve is a form of quarter-turn valve which uses a floating
ball to control flow through it.
3PC flanged ball valves are generally slightly reduced (or
standard) bore, they can be either throw-away or repairable.
Size: 1/2"-4"
Full Port
Seat or Sealing: PTFE or as request.
Temperature Range: -20℃ to 150℃
Working Medium: Water, Oil, Gas, Acid, etc
Blow-Out Proof Stem
Investment Casting Body
Design ACC: ASME B16.34
Face to Face: DIN PN16-40
Flange Dimensions: DIN2633
Inspection&Testing Acc: API 598
Main export markets:
- European markets
- Central/South America
- Middle East
- South Africa
- Asia
KIRI VALVE is an ISO9001 certified manufacturer of stainless
steel/wcb industrial valves: Ball Valve, Check valve, Gate Valve,
Globe Valve, Y-strainer, pipe fittings etc.
Specification
| Item No | Part Name | Material |
| 1 | Nut | SS304/SS201 |
| 2 | Spring Washer | SS304/SS201 |
| 3 | Cap | CF8M/CF8/WCB |
| 4 | Body Gasket | PTFE/RPTFE |
| 5 | Ball Seat | PTFE/RPTFE |
| 6 | Ball | SS316/SS304/SS201 |
| 7 | Body | CF8M/CF8/WCB |
| 8 | Thrust Washer | PTFE |
| 9 | O-Ring | Viton |
| 10 | V-Ring Packing | PTFE |
| 11 | Gland | SS304/SS201 |
| 12 | Belleville Washer | SS304/SS201 |
| 13 | Stop Nut | SS304/SS201 |
| 14 | Stop Washer | SS304/SS201 |
| 15 | Washer | SS304/SS201 |
| 16 | Handle | SS304/SS201 |
| 17 | Stem Nut | SS304/SS201 |
| 18 | Locking device | SS201 |
| 19 | Handle Cover | PLASTIC |
| 20 | Stem | SS316/SS304/SS201 |
| 21 | Bolt | SS304/SS201 |
| Size | φd | L | H | H2 | W | φR | φC | φD | οP | N-φM | T | F | Torque N.M | ISO 5211 |
| 1/2” | 15 | 130 | 77 | 8 | 110 | 45 | 65 | 95 | 9 | 4-14 | 14 | 2 | 7 | F03/F04 |
| 3/4” | 20 | 150 | 89 | 8 | 110 | 58 | 75 | 105 | 9 | 4-14 | 16 | 2 | 9 | F03/F04 |
| 1” | 25 | 160 | 92 | 10 | 160 | 68 | 85 | 115 | 11 | 4-14 | 16 | 2 | 11 | F04/F05 |
| 1-1/4” | 32 | 180 | 97 | 10 | 160 | 78 | 100 | 140 | 11 | 4-18 | 16 | 2 | 18 | F04/F05 |
| 1-1/2” | 38 | 200 | 111 | 14 | 185 | 88 | 110 | 150 | 14 | 4-18 | 16 | 3 | 23 | F05/F07 |
| 2” | 50 | 230 | 120 | 14 | 185 | 102 | 125 | 165 | 14 | 4-18 | 18 | 3 | 28 | F05/F07 |
| 2-1/2” | 65 | 290 | 145 | 18 | 250 | 122 | 145 | 185 | 17 | 4-18 | 18 | 3 | 55 | F07/F10 |
| 3” | 78 | 310 | 456 | 18 | 280 | 138 | 160 | 200 | 17 | 8-18 | 20 | 3 | 90 | F07/F10 |
| 4” | 100 | 350 | 168 | 18 | 310 | 158 | 180 | 220 | 19 | 8-18 | 20 | 3 | 120 | F07/F10 |
